SkyWatcher MAK 90 is an optical tube in the Maksutów - Cassegrain system with a diameter of 90 mm and a focal length of 1250 mm.
Tuba works as a short balcony planetary spotter, providing very high contrast when observing bright and compact objects (Moon, planets, bright clusters and galaxies), because it is practically free of chromatic aberration and is not sensitive to atmospheric instability. . In addition, it is a good choice for those who are looking for a very portable telescope with a lot of observation possibilities, one that will be a companion for many trips to the dark, rural sky, while occupying very little space in the trunk of the car.
The Maksutowa-Cassegrain optical system is one of the most valued optical constructions, widely appreciated for its mobility, ease of use and multi-functionality. It is an excellent choice of both astronomical observations, as well as earth observations and aircraft observations. Excellent optics provide an extremely sharp image throughout the field of view. The telescope consists of the meniscus correction board, the main mirror and the secondary mirror placed on the inner part of the meniscus. These telescopes have a reduced coma and show only a substantial chromatic aberration, giving very sharp and expressive images. A great advantage of the Maksutov telescopes is the compact and compact design and light weight. Due to their large focal length and low light, they are perfectly suitable for planetary observations. This type of construction works well in urban environments, where the main emphasis is on solar system objects, not on nebulae.
Additional advantages
• focusing
Focusing is performed not through the external sliding puller, but through the micrometer screw moving the main telescope mirror. This method of focusing the image provides a very wide range of sharpness adjustment, thanks to which virtually any astronomical accessories work well with the tube, and the clearances on the extractor simply do not exist.
• T2 thread in the eyepiece extractor
The eyepiece extractor is equipped with a T2 thread (M42x0.75), so you only need a T2 ring for the bayonet of your camera to connect the SLR (Nikon, Canon EOS, Sony ?, Olympus E, Olympus 4/3, Pentax K). In this way, we can use the telescope to take pictures of the Moon and planets or use it as a 1250mm f / 14 telephoto lens.
• fixing to a photographic tripod
The tube can be attached to any rigid photographic tripod through a standard 1/4 inch thread.
Moon the planet star clusters nebulae scenery
| • Optical system: | Maksutow - Cassegrain | | • Lens diameter: | 90 mm | | • Focal length of the lens: | 1250 mm | | • Lighted: | 1/14 | | • Switching capacity: | 1,3 ' | | • Theoretical range: | 12.5 magnitude | | • Maximum useful magnification: | 180x | | • Dimensions of the optical tube [cm]: | 10 x 10 x 24 | | • Weight of the optical tube: | 1.5 kg |
The set includes the following accessories: • 1.25 "focuser
• Glasses: PL 20mm (over 62.5x) and 10mm (over 125x) - in 1.25 "standard, 50 ° own field of view
• Angled mirror 90 ° (gives an uninverted, terrestrial image)
• Star Pointer type finder (collimator)
• Cover / transport bag 3 years
READ : A SHORT OPTICAL CLEANER GUIDE
 [PDF]
READ TO: HOW TO CONNECT COMPACT WITH TELESCOPIC
[PDF]
READ TO: HOW TO JOIN THE DIGITAL MALE WITH A TELESCOPIC
[PDF]
(Moon, click to enlarge)
(Moon, click to enlarge)
(Moon, click to enlarge)
|
