Leupold VX-5HD Gen 2 1-5x24 (30 mm) Metric Illuminated FireDot 4 Fine Riflescope (SKU: 183844)

Leupold VX-5HD Gen 2 1–5×24 (30 mm) Metric Illum. FireDot 4 Fine riflescope (Leupold, SKU: 183844) is a riflescope for sport shooting and field use. Variable magnification lets you adjust the image scale to the distance of the observed target.

Key features

• second focal plane reticle keeps a constant apparent size as magnification changes
• illuminated reticle makes the aiming mark easier to see against the observed subject
• the Pop-Up dials simplify resetting the zero reference
• the MST system controls illumination according to detected movement
• the Guard-ion coating helps reduce water and dirt adhesion to the lenses
• optical design: Professional-Grade Optical System
• waterproof and internally fogproof construction

Included items

• riflescope Leupold VX-5HD Gen 2 1–5×24 (30 mm) Metric Illum. FireDot 4 Fine

Technical specifications

• magnification: 1–5×
• objective lens diameter: 24 mm
• maintube diameter: 30 mm
• reticle: FireDot 4 Fine
• reticle focal plane: second focal plane (SFP)
• reticle illumination: yes
• elevation adjustment mechanism: Pop-Up Rezero
• windage adjustment mechanism: Pop-Up Rezero
• click value – elevation: 1 cm / 100 m
• total adjustment range – elevation: 524 cm / 100 m
• adjustment per revolution – elevation: 80 cm / 100 m
• click value – windage: 1 cm / 100 m
• total adjustment range – windage: 524 cm / 100 m
• adjustment per revolution – windage: 80 cm / 100 m
• fixed parallax-free distance: approx. 137.2 m (150 yd)
• field of view at min./max. magnification: approx. 38.5 / 7.97 m / 100 m
• angular field of view at min./max. magnification: 21.8 / 4.6°
• eye relief at min./max. magnification: approx. 96.5 / 99.1 mm
• battery type: CR2032
• brightness settings: 8
• battery life at low intensity: 1600 hr
• battery life at medium intensity: 1000 hr
• battery life at high intensity: 300 hr
• night-vision-compatible illumination: no
• overall length: approx. 271.8 mm
• total mounting space: approx. 172.7 mm
• front mounting space: approx. 71.1 mm
• rear mounting space: approx. 55.9 mm
• eyepiece assembly length: approx. 83.8 mm
• objective assembly length: approx. 17.8 mm
• objective housing outside diameter: approx. 30.5 mm
• eyepiece housing outside diameter: approx. 45.7 mm
• weight: approx. 425 g

Selecting the magnification and setting the described adjustments lets you adapt the scope to the viewing conditions.
