The Askar 107PHQ is an astrograph that, thanks to its optical characteristics, will be perfect for people taking their first steps in professional astrophotography, as well as for the role of the basic optical tube in the arsenal of the most experienced and demanding users.
The heart of this telescope is a four-element apochromatic optics with an air gap. In order to ensure the best possible correction of chromatic aberrations, Askar designers decided to use a solution known from the most expensive, flagship apochromats, namely the use of two lenses made of glass with reduced dispersion (ED). In addition to the excellent color reproduction, the Askar 107PHQ is characterized by a negligible field curvature, thanks to which, even without the use of an additional flattener, the image on the edge of the frame is free from noticeable distortions.
The possibilities of this telescope are not limited to astrophotography, however. This instrument makes it possible to conduct visual observations after connecting the angular cap or glasses with a diameter of 1.25 "and 2".
In addition to impeccable optical parameters, Askar 107PHQ is characterized by high quality and precision of mechanical parts. A solid extractor allows the installation of even the heaviest astronomical cameras, and the mounting rings and the Vixen foot made in the CNC technology guarantee full stability of the tube. • high-class astrograph with two low-dispersion lenses, eliminating the formation of chromatic aberrations
• advanced optical design guarantees perfect field curvature correction without the need for an additional flattener
• four-element adapter enabling connection of various cameras or photo cameras
• The diameter of the full illumination disc to cover the full frame
• a solid hood that guarantees linearity even with a load of 8 kg
• can also be used in visual observations • optical construction: apochromatic refractor
• Lens array: ED quadruplet with air gap
• number of low dispersion lenses: two
• Front lens diameter (aperture): 107 mm
• focal length: 749 mm
• lighted: f / 7
• circle diameter of full illumination: 44 mm
• compatibility with full frame matrices: yes
• adapter for connecting the camera / camcorder: four elements
• back focus for adapter with M48x0.75 thread (from the thread base): 79 mm
• back focus for adapter with M54x0.75 thread (from the thread base): 99 mm
• back focus for adapter with M68x1 thread (from the thread base): 119 mm
• back focus for adapter with M86x1 thread (from the thread base): 149 mm
• compatible glasses / angle attachments: 1.25 ", 2"
• possibility of installing a filter: 2 "in an adapter M52x0.75 - M48x0.75
• diameter of the lift: 3.4 "
• maximum focus load: 8 kg
• focus adjustment range: 95 mm
• mounting for assembly: Vixen foot
• length of the tube with the unfolded reference point: 754 mm
• length of the tube with a folded-in plug: 603 mm
• weight of the tube without accessories: 5.7 kg
• weight of the tube with accessories: 6.9 kg • Askar 107PHQ optical tube
• four-element M86 - M48 photographic adapter
• mounting clamps
• Vixen 300 mm rail
• aluminum transport case 24-month manufacturer's warranty
|
