Player One R31+R27 4P Tilt Adjustment Plate for Cooled Cameras with Carbon Fibre Housings (SKU: POA-TP85-M42) enables Ares, Uranus Pro and Apollo Pro series cameras to be connected to selected Phoenix filter wheels and the Filter Drawer MAX. The 4P mechanism provides four-point sensor tilt adjustment with screw access from the camera side.

Tilt adjustment allows the sensor plane to be aligned relative to the optical axis, reducing focus differences caused by sensor tilt. The plate is made from 6061-T6 aluminium. It features a central T2 (M42 × 0.75) female thread and two mounting hole patterns, R31 and R27. The extension length is 8 mm.

Key features

• four-point tilt adjustment with access from the camera side
• connection of cameras with carbon fibre housings to larger Phoenix filter wheels and the Filter Drawer MAX
• two mounting hole patterns, R31 and R27
• central T2 female thread and 6061-T6 aluminium construction

Set contents

• Player One R31+R27 4P tilt adjustment plate — 1 piece

Technical specifications

• type: mounting plate with a tilt adjustment mechanism
• adjustment: four-point, with access from the camera side
• material: 6061-T6 aluminium
• central thread: T2 female, M42 × 0.75
• extension length: 8 mm
• outer diameter: 88 mm
• R31 pattern: 6 through holes measuring 2.7 mm in diameter on a circle with a radius of 31 mm
• R27 pattern: 6 through holes measuring 2.7 mm in diameter on a circle with a radius of 27 mm
• compatible cameras: Player One Ares, Uranus Pro and Apollo Pro series cooled models with carbon fibre housings
• compatible filter wheels: Player One Phoenix 7 × 36 mm, 7 × 2", 7 × 50 mm, 5 × 2"
• compatible filter drawer: Player One Filter Drawer MAX
• colour: black
