NexImage Solar System Imager is a complete system for recording high quality images of the Solar System. High sensitivity and faithful color reproduction are the basic features of the camera offered in the set. In conjunction with the Registax software included in the package, NexImage brings out a huge amount of detail.
The software automatically filters the video signal, leaving only the sharpest and most-frequent frames of the film to put them into one high quality image.
An easy-to-use program and sample lesson together with a sample video will allow you to get breathtaking images of the first night!
The software allows you to manually adjust the gain, contrast, exposure time, image refresh rate and color saturation.
NexImage is mounted instead of the telescopic eyepiece in the eyepiece or in the corner attachment.
| • Resolution (display, photos and videos): || 640x480 pixels |
| • The size of a single pixel: || 5.6 ?m x 5.6 ?m |
| • Matrix: || 1/4 ", HAD, colored |
| • Sensitivity of the matrix: || <1 Lux |
| • Power supply: || from the computer's USB port |
| • Camera mounting diameter: || 1.25 "(31.7 mm) |
| • Mounting to the telescope: || instead of an optical eyepiece, in the extractor |
| • USB port properties: || supports both USB 2.0 and USB 1.1 |
| • Compatible operating systems: || Windows 98, Windows XP, Vista, Windows 7 (directly or XP Mode) |
| • Weight: || 50 g |
• operating system: Windows 98SE or newer
• processor: 333Mhz Pentium II or higher
• RAM memory: min. 128 MB
• disk space: 40 MB
• screen resolution: 1024x768 or higher
A colorful webcam for a simple planetary astrophotography, nicely reflecting the colors of the observed objects, good for the beginning of the adventure with the perpetuation of the daytime and the night sky, it can also be used to observe and record nature, shows for organized groups.
The set includes drivers and a program that records and processes videos.
For testing, I used the SCT 8 "telescope and its 7x50 finder.
A successful photo is not only a good camera, but also good weather, collimation, seeing, and aperture of the telescope - the bigger, the more details the webcam will show.
Sun: finder 7x50 with foil Baader and in focus SCT8 "(sunspot)
Venus in various periods of growth of the SCT 8 "+ Barlow 3x TV target
Moon, finder 7x50
SCT 8 "main focus, mosaic
Main focus SCT 8 "
Jupiter: main focus, Barlow 2x and 3x
Saturn, SCT 8 "Barlow 2x
Uranium, main focus SCT 8 "
